Macomb Group 0300156007 2-1/2 x 1 ci thrd ecc reducer

Product Description

The MACOMB GROUP 0300156007 is an eccentric reducing coupling, Model 368, designed for Class 125 pressure applications. Constructed from cast iron with a black finish, it adheres to ASTM A126 Class A Minimum material standards. It has a nominal size of 2-1/2 X 1 IN and features FNPT connection type with STD schedule.

• Eccentric Reducing Coupling
• Cast Iron Construction
• Black Finish

Product Highlights

This coupling is UL Listed and FM Approved, ensuring quality and safety. It is suitable for use in a variety of piping systems.

Product Information

Standard Information

• Brand: MACOMB GROUP
• Manufacturer Part Number: 0300156007
• Country of Origin: Domestic

Technical Specifications

• Series/Model: Model 368
• Pressure Class: Class 125
• Nominal Size: 2-1/2 X 1 IN
• Connection Type: FNPT
• Schedule: STD
• Material: Cast Iron
• Material Standard: ASTM A126 Class A Minimum
• Finish/Color: Black
• Length: 2-1/4 IN
• Maximum Pressure: 175 PSI
• Temperature Rating: -20 To 150 DEG F
• Industry Standards: ASME B16.4, ASME B1.20.1
• Listings: C/US UL Listed, FM Approved
• Domestic/Import: Domestic
• Weight: 2.740 LB
