M&M MANUFACTURING 221 M&M Manufacturing PL-221 Labeler

Product Description

The M&M Manufacturing PL-221 Labeler is a versatile machine designed to apply labels to both the top and bottom of products at the same time. Its adjustable guide rails allow for various label sizes, ensuring compatibility with different packaging types. The unit features durable stainless steel and aluminum construction, along with a stainless steel control box that enhances its reliability.

• Applies top and bottom labels simultaneously.
• Adjustable guide rails accommodate various label sizes.
• Includes a built-in counter for tracking labeled products.

Product Highlights

This labeler is ideal for production lines where efficiency and precision are necessary.

Product Information

Standard Information

• Model: PL-221
• Manufacturer: Pack Leader

Technical Specifications

• Voltage: 220/110 VAC
• Frequency: 50/60Hz
• Phase: 1 ph
• Power Consumption: 825 VA
• Applicator Height: 150 mm
• Maximum Label Height: 150 mm
• Maximum Label Length: 300 mm
• Label Roll Outer Diameter: 300 mm
• Core Diameter: 3 inch / 76 mm
• Conveyor Width: 200 mm
• Adjustable Conveyor Guide Rails: up to 250 mm
• Conveyor Speed: 5~40 m/min
• Dispensing Speed: 40 m/min
• Dispense Driver: stepper motor
• Drive Motor Enclosure Rating: IP55
• PLC: Panasonic
• HMI: Delta
