Lutron MACL-LFQ-GR Maestro LED+ Fan/Light Control 120V/75W Dimmable LED or 250W Incandescent/Halogen Light, 1.5A Fan

Product Description

The Lutron MACL-LFQ-GR Maestro Dual LED+ Dimmer and 4-Speed Fan Control helps you achieve the ideal comfort level for your home. It includes the most advanced technology for superior dimming and adjust the fan speed all from one wall control. The LED+ Dimmer works with up to 75W of dimmable LEDs or up to 250W of Incandescent/Halogen bulbs and the 4-speed fan control is for a single ceiling paddle fan up to 1.5A.

• Advanced technology for superior dimming
• Adjust fan speed all from one wall control
• LED+ Dimmer portion has easy low-end trim programming

Product Highlights

The Maestro LED+ fan/light control manages lighting and fan speed from one wall location. It features a dimmer for LED, CFL, halogen and incandescent bulbs and provides four fan speeds.

Product Information

Standard Information

• Brand: LUTRON
• Manufacturer Part Number: MACL-LFQ-GR
• Country of Origin: CN

Technical Specifications

• Type: Fan Control
• Depth: 1.85 Inches
• Width: 2.95 Inches
• Height: 4.68 Inches
• Actuator: Tap switch
• Mounting: Screw
• Standard: UL
• Connection: Screw terminal
• Voltage Rating: 120 VAC
• Amperage Rating: 1.5 Amperes
• Number Of Poles: Single-Pole
• Country of Origin: CN
• Operating Temperature: 104°F
• Environmental Conditions: Dry Location
• Sub Brand: Maestro
• Application: For use in single-pole applications, where the fan/light is controlled from one location
• Contact Rating: 1.5 A fan
• Enclosure: Plastic
• Special Features: Dimmer (top) Tap on dimmer to preset light level; tap off. Tap twice for full on. Touch rocker to adjust light level. Fan control (bottom) Tap on to preset fan speed; tap off. Touch rocker to adjust speed. 4-quiet fan speeds plus off provide enhanced comfort. Designed to prevent motor hum. For use with only one fan/light.
• UPC: 784276239356
• GTIN: 00784276239356
• Item Type: Digital preset fan/light control
• Size: 4.69 in (119 mm) x 2.94 in (75 mm)
• Wattage: 75 W dimmable LED/CFL or 250 W incandescent/halogen light
• Bulb Compatibility: Up to 75W of dimmable LEDs or up to 250W of Incandescent/Halogen bulbs
• Fan Control: 4-speed fan control for a single ceiling paddle fan up to 1.5A
• Voltage: 120V
• Pole Configuration: Single-Pole
• Installation: Screw terminal and wire lead installation
• Neutral Required: No
• Canopy Module Required: No
• Switch Type: Button
• Input Voltage: 120V
• Finish: Gloss Grey
• Style & Type: Decorator/Rocker dimmer, Decorator/Rocker fan control
• Overall Dimensions: 4.0 in x 2.0 in x 2.0 in (h x w x d)
• Wiring Type: Single pole
• Wiring Requirements: No neutral wire required
• Indoor / Outdoor: Indoor
• Ratings: 75W LED, 250 W incandescent/halogen, 1.5 A fan
• Fan Control/Dimmer Switch: Provides best LED dimming performance
• Compatibility: For use with ceiling fans with pull chains; not compatible with fans with remotes
• Programmable Fade: Programmable fade of the dimmer gradually turns lights on, allowing your eyes to adjust to the change in light and gradually fade off, allowing time to exit a room before the lights turn off
• Dimmer Wattage: Dimmer works with up to 75-Watt of dimmable LED's or CFLs or up to 250-Watt of incandescent or halogen
• Fan Control Amperage: Fan control works with up to 1.5 Amp ceiling paddle fan
• Fan Speed: Fan control provides 4 quiet fan speeds for increased comfort
• Operation: Easy-to-operate tap switch turns lights or fan on and off; rockers next to switches dim/brighten lights and increase/decrease fan speed
• Installation Time: Installs in as little as 15 minutes
• Includes: Includes (1) fan/light control; coordinating wallplate sold separately
