Lufkin LSSP6-07 Extendable Layout Tool 90 Deg Sae

Product Description

The LUFKIN LSSP6-07 is a 2-in-1 extendable layout tool designed for precise angle layout and measurement on job sites. Built from aluminum with a rawhide black finish, it functions as both a compact square and an extended rule, covering a measuring range of 0 to 12.5 inches. The blade extends from a contracted length of 6.5 inches to a full extended length of 12.52 inches, giving tradespeople a versatile single tool for two common tasks. The fixed 90-degree bend angle makes it suited for squaring work across multiple trades. It reads SAE measurements and weighs 0.73 pounds, keeping it light in a tool bag or pouch.

The LSSP6-07 is intended for use in layout and marking applications across carpentry, electrical rough-in, HVAC duct work, plumbing, and general construction. Its compact contracted length of 6.5 inches fits easily in a tool pouch, while the extended position reaches 12.52 inches for wider layout work. The extendable design reduces the need to carry separate squares and rules for standard residential and light commercial framing or fitting tasks.

Key Features

• 2-in-1 design functions as a compact square and an extended layout rule in a single tool
• Blade extends from 6.5 inches to 12.52 inches for flexible measuring range
• Fixed 90-degree bend angle for consistent squaring and marking
• Aluminum construction keeps weight at 0.73 pounds
• SAE graduation for standard inch-based layout work
• Rawhide black finish for visibility and corrosion resistance on job sites

Compatibility

Designed as a general-purpose SAE layout tool for trade professionals performing layout and marking tasks in residential and light commercial construction and service work.

Installation Notes

No power tools or fasteners are required for use. Keep the blade locking mechanism free of debris to ensure accurate extended length is maintained during marking. When using as a square, verify the 90-degree reference against a known surface before scribing critical layout lines. Sold as an individual unit.

Technical Specifications

• Blade Length: 12.5 inches
• Contracted Length: 6.5 inches
• Extended Length: 12.52 inches
• Measuring Range: 0 to 12.5 inches
• Bend Angle: 90 degrees
• Measurement Type: SAE
• Material: Aluminum
• Color: Rawhide Black
• Weight: 0.73 pounds
• Width: 7.25 inches
• Height: 1.2 inches

Standard Information

• Brand: LUFKIN
• Manufacturer Part Number: LSSP6-07
