Ls Electric 6121000700 SV0110IS7-4NOFD 15HP

Product Description

The LS Electric SV0110IS7-4NOFD, MPN 6121000700, is a high-performance sensorless vector drive with optional closed-loop control, PLC capability, and pump jack control. It is available in 400-480V, 3 phase. The drive features three option slots for fieldbus, extension, and encoder options. It has a built-in DC reactor for harmonic reduction and power factor improvement.

• Control mode: V/F, V/F PG, Sensorless Vector, Vector
• Standard Protection Rating: IP21, optional IP54 enclosure (~ 22kW)
• Speed Control Range 1:100(Sensorless Vector), 1:1000(Vector)

Product Highlights

This variable frequency drive is suitable for elevator, construction lift, crane/hoist, and other industrial applications. It offers improved accuracy in speed and torque operation.

Product Information

Standard Information

• Brand: LS Electric
• Manufacturer Part Number: 6121000700

Technical Specifications

• Alternate Part Number: 6121000700
• Horsepower: 15 hp
• Housing/Enclosure: Enclosed
• Input Phase: 3 Phase
• Input Voltage: 400-480V, 3 Phase
• Outdoor Rated: No
• Output: 3 Phase Output
• Series: iS7 Series
• Options: Built-In DC Reactor, Enclosed, Integrated EMC Filter
• STO (Safe Torque Off): No
• Torque Load: Constant/Variable (CT/VT)
• Drives - Type of Drive: High Performance
• Brand: LS Electric
• Model #: SV0110IS7-4NOFD
• Input Voltage Range (VAC): 400Volts- 480 Volts
• HP: 15-20Horsepower
• Amps: 24Amps – 30 Amps
• Drive Application: High Performance, Sensorless Vector
• Communication: BACnet, Modbus-RTU, Metasys N2
• IP Rating: IP20
• Condition: New
• Manufacturer Part Number: 6121000700
• Manufacturer: LS Electric
• Product Series: IS7
• Family Series: LS Electric Drives, IS7 Series
• Description: 15HP 460V Three Phase VFD, IP20 Enclosure, No Keypad, DC Link Inductor, and EMI/RFI Filter
• Phase: 3
• HP (Constant Torque Rating): 15 hp
• HP (Variable Torque Rating): 20 hp
• Amps (Constant Torque Rating): 24 A
• Amps (Variable Torque Rating): 30 A
• Brake: DJ Injection
• Closed Loop: No
• AC Line Regenerative: No
• Operator Controls: Built In
• NEMA Rating: NEMA 1
• Motor Control-Max Level: Open Loop Vector (Sensorless Vector)
• Mounting: DIN Rail
• Nominal Input Voltage: 380 VAC, 415 VAC, 480 VAC
• AC Voltage: 380-480 VAC
• Primary brand: LSIS
• Main function: Variable Speed/Frequency Drive (VSD/VFD) / Inverter
• Product series / family name: LS-iS7 series
• Network frequency (input): 50/60 Hz
• Network frequency (output): 0.01-400 Hz
• Network frequency (output sensorless-1 control): 0.01-300 Hz
• Network frequency (output sensorless-2 / sensored control): 0.01-120 Hz
• Functions: Variable Speed/Frequency Drive (VSD/VFD) / Inverter
• V/f control: V/f PG control
• Slip compensation: Sensorless-1 vector
• Sensorless-2 vector: Sensored vector
• Auto & Manual torque boost: PID control
• Up-Down operation: 3-wire operation
• DC braking: Frequency limit
• Second function: Reverse rotation prevention
• Auto restart: Drive By-pass
• Auto-tuning: Energy buffering
• Power braking: Flux braking
• Low leakage: MMC
• Easy start: Design
• built-in EMC filter: built-in DC reactor
• 3-phase 400V class: Frame size 3
• heatsink out the back: Supply voltage (AC)
• Supply voltage (AC): 380Vac-480Vac (3-phase) (-15%...+10%) (400Vac / 415Vac / 440Vac)
• Rated current: 30A (VT; normal duty)
• Rated active power (kW): 11kW
• Rated power (HP): 15HP
• Protection functions: Over current
• Over voltage: Low current
• External trip: Ground fault
• Drive overheat: I/O phase open
• Overload: Communication error
• Frequency command loss: Hardware fault
• Fan fault: Pre-PID fault
• No motor trip: External brake trip
• Communication protocol: RS-485
• Digital inputs: 4 x digital inputs (24Vdc; NPN/Sink or PNP/Source) (FX Forward; RX Reverse; BX Emergency stop; RST Reset)
• Digital outputs: 2 x digital inputs (Safe-Torque OFF STO A and B)
• 1 x digital output: (SPDT Form-C NO/NC rly. contact; 1A at 250Vac/30Vdc)
• 1 x digital output (open-collector: 26Vdc; below 100mA)
• Analog inputs: 1 x analog input (-10...+10Vdc / 0-10Vdc / 0-20mA)
• Analog outputs: 1 x analog outputs (0-10Vdc / 0-20mA / 4-20mA)
• Degree of protection: NEMA 1
• Ambient air temperature for operation: -10...+50 °C
• Rated apparent power (S): 17.5kVA
