Ls Electric 6031000900 Vfd 15 Hp 460V Three Phase IP20

Product Description

The LS ELECTRIC 6031000900 is a three-phase variable frequency drive (VFD) rated for 15 HP at 460 volts in heavy-duty (constant torque) service. It accepts three-phase input in the 380 to 480 VAC range and delivers up to 15 A of output current in heavy-duty mode, supporting 150% overload for 60 seconds. A built-in EMC/EMI/RFI filter reduces conducted emissions without requiring an external filter. The drive ships with an integrated LED 7-segment keypad and carries an IP20/NEMA 1 enclosure rating. Licensed HVAC technicians, industrial electricians, and OEM panel builders install this unit in variable-speed motor control applications.

The 6031000900 is suited for commercial and light-industrial motor control tasks including fans, pumps, compressors, and conveyor systems where precise speed regulation and energy savings are priorities. The sensorless vector and V/F control modes allow flexible configuration for both variable-torque and constant-torque loads. At 11.4 inches tall, 7.1 inches wide, and 6.4 inches deep, it fits in standard control enclosures without a large footprint. The drive is appropriate for new installations and retrofit projects operating on 460-volt three-phase power systems.

Key Features

• 15 HP heavy-duty (CT) output at 460V three-phase with 150% overload capacity for 60 seconds
• Built-in EMC/EMI/RFI filter eliminates the need for a separate external filter
• Sensorless vector and V/F control modes for variable- and constant-torque applications
• Integrated LED 7-segment keypad for on-drive parameter programming and monitoring
• IP20/NEMA 1 enclosure suitable for protected indoor panel installations
• Heavy-duty single-phase input rated at 26.5 A for flexible sourcing scenarios

Compatibility

Designed as a three-phase 460V variable frequency drive replacement or new-installation unit for motors rated up to 15 HP in heavy-duty constant-torque service on 380 to 480 VAC systems.

Installation Notes

Installation should be performed by a licensed electrician in accordance with the NEC and all applicable local codes. Disconnect and lock out all power to the circuit before mounting or wiring the drive. Maintain adequate clearance around the enclosure for ventilation as specified in the manufacturer documentation. Do not connect the output terminals directly to the utility supply or apply power-factor correction capacitors to the output side of the drive.
