Lovejoy L110HUB13T8/16 L Type Jaw Coupling Hub

Product Description

The Lovejoy L110HUB13T8/16 is a reliable L Type Jaw Coupling Hub designed for a standard shaft-to-shaft connection in various industrial applications. This coupling hub offers effective performance with a sintered iron construction, ensuring durability. The Centraloc spline locking feature enhances its stability.

• Standard shaft-to-shaft connection
• Constructed from sintered iron
• Includes Centraloc spline locking feature

Product Highlights

This coupling hub is ideal for industrial-duty settings, providing support for smooth operation.

Product Information

Standard Information

• Brand: Lovejoy
• Part Number: L110HUB13T8/16

Technical Specifications

• Lock Type: Setscrew
• Spline Description: 8/16
• Hub Diameter: 3.32 in
• Overall Length: 4.22 in
• Spline Size: 13T 16/32 DP
• Outside Diameter: 3.32 in
• Number of Teeth: 13
• Max RPM: 5000 rpm
• Material: Sintered Iron
• Coupling Size: 110, L110
• Length Through Bore: 1.68 in
• Weight: 2.4 lb
• EAN or UPC: 685144379153
