Lovejoy L099HUB15T16/32 L Type Jaw Coupling Hub

Product Description

The Lovejoy L099HUB15T16/32 is an L Type jaw coupling hub designed for standard shaft-to-shaft connections in industrial applications. This coupling hub is constructed from sintered iron, ensuring durability and reliability in various settings.

• Provides standard shaft-to-shaft connection for general industrial applications
• Constructed from sintered iron
• Features a Centraloc spline locking feature

Product Highlights

This coupling hub is ideal for use in machinery where reliable performance is essential. The design facilitates efficient power transmission with minimal backlash, making it suitable for high-speed operations.

Product Information

Standard Information

• Brand: Lovejoy
• Part Number: L099HUB15T16/32

Technical Specifications

• Coupling Size: 099, L099
• Coupling Type: Jaw
• No. of Teeth: 15
• Length Through Bore: 1.06 inches
• Overall Length: 2.84 inches
• Max RPM: 7000 rpm
• Lock Type: Setscrew
• Material: Sintered Iron
• Hub Diameter: 2.54 inches
• Spline Description: 16/32
• Spline Size: 15T 16/32 DP
• Outside Diameter: 2.54 inches
• Weight: 1.22 pounds
• EAN or UPC: 685144385741
