Lovejoy F5.5ESLEEVE Sier-Bath Coupling Sleeve | 6.910 inches | 573300 in lb

Product Description

The Lovejoy F5.5ESLEEVE is a high-quality Sier-Bath coupling sleeve designed for efficient power transfer. This sleeve is made from a single piece of alloy steel and can handle both angular and parallel misalignment.

• Durable O-ring seals for improved performance
• Suitable for driver and driven applications
• High torque rating of 573300 in lb

Product Highlights

The product ensures reliable operation with features that enhance its longevity and performance, including heat-treated bolts and patented gear tooth technology.

Product Information

Standard Information

• Brand: Lovejoy
• Type: Standard Sleeve

Technical Specifications

• Flange Type: Exposed Bolt
• Seal Type: O-Ring
• Application: Driver and Driven
• Bolt Circle Diameter: 14.5 inches
• Max RPM: 2200 rpm
• Bolt Holes: 14
• HP @ RPM: 910 hp @ 100 rpm
• Coupling Size: F5.5
• Torque Rating: 573300 in lb
• Length: 6.910 inches
• Size of Bolts: 7/8 - 14
• Material: 1045 Carbon Steel
• Weight: 83.5 lb
• EAN or UPC: 697904003680
