Lovejoy F3.5SSLEEVE F3.5 SLEEVE | Sier-Bath Coupling Sleeve

Product Description

The Lovejoy F3.5SSLEEVE is a Sier-Bath coupling sleeve designed for high performance in various applications. This product features a smooth, one-piece alloy steel sleeve with options for either exposed or shrouded bolt designs. It is built to handle high-strength requirements due to heat-treated bolts that resist corrosion. Patented Vari-Crown gear teeth promote longevity, making it suitable for demanding environments.

• Ideal for driver and driven applications
• Compensates for angular, parallel, and axial misalignment
• Supports larger bore capacities for enhanced performance

Product Highlights

Available for quick shipping, the Lovejoy F3.5SSLEEVE is perfect for HVAC, mechanical, and industrial applications.

Product Information

Standard Information

• Brand: Lovejoy
• Part Number: F3.5SSLEEVE

Technical Specifications

• Seal Type: O-Ring
• RPM [Max]: 3500 rpm
• Style: Shrouded Bolt Sleeve
• HP @ RPM: 240 hp @ 100 rpm
• Bolt Holes: 12
• Flange Diameter: 11 in
• Length Through Bore: 4.19 in
• Size of Bolts: 5/8 - 18
• Bolt Circle Diameter: 9.281 in
• Material: 1045 Steel
• Torque Rating: 151200 in lb
• Coupling Size: F3.5
• Bore Diameter [Max]: 4.9210 in
• Weight: 21.62 LB
