Lovejoy F3.5HUB RSB | F Series Gear Coupling Hub

Product Description

Lovejoy F3.5HUBRSB is a robust gear coupling hub designed to handle demanding applications. This hub is part of the F Series, known for its reliability and strength in power transmission systems. It features a rough stock bore, which allows for a maximum bore diameter of four and five-eighths inches.

• Torque capacity of 151200 in lb
• Suitable for various applications with a speed of up to 3500 rpm
• Constructed with a durable AISI 1045 material for optimal strength

Product Highlights

This gear coupling hub is built with patented gear teeth and O-ring seals, providing enhanced performance and longevity. Its design compensates for misalignments and accommodates higher speeds, making it ideal for mechanical power transmission tasks.

Product Information

Standard Information

• Brand: Lovejoy
• MPN: F3.5HUBRSB

Technical Specifications

• Torque Rating [Max]: 151200 in lb
• Hub Diameter: 6 1/2 in
• Bore Diameter [Max]: 4 5/8 in
• Color: Metallic
• HP @ RPM: 240 hp @ 100 rpm
• Outside Diameter: 6.5 in
• Length Through Bore: 4.19 in
• Flange Diameter: 11 in
• Coupling Type: Gear
• Overall Length: 8.63 in
• RPM [Max]: 3500 rpm
• Bore Diameter [Min]: 1 13/16 in
• Distance Between Shaft Ends: 1/4 in
• Bore Type: Rough Stock Bore
• Material: AISI 1045
• Coupling Size: 3.5, 3 1/2
• Input Bore Range: 1 13/16 to 4 5/8
• Weight: 40.0 lb
• EAN or UPC: 697904002072
