Lovejoy 9HSLEEVE S-Flex Coupling Sleeve 9 Replacement MPN

Product Description

The Lovejoy 9HSLEEVE is a S-Flex Coupling Sleeve that provides reliable coupling functionality across various applications. Designed for double engagement, it enhances shock control and dampens vibrations effectively. The sleeve eliminates lubrication requirements, ensuring a maintenance-free operation. It has flexible external teeth for easy installation.

• Double engagement design
• Maintenance-free operation
• Torsionally soft for shock control

Product Highlights

The Lovejoy 9HSLEEVE features a durable Hytrel® material, which allows it to withstand a temperature range from negative sixty-five degrees Fahrenheit to two hundred fifty degrees Fahrenheit. Its one-piece construction and high maximum RPM rating ensure it meets industrial needs.

Product Information

Standard Information

• Brand: Lovejoy
• Part Number: 9HSLEEVE

Technical Specifications

• Material: Hytrel®
• Length: 1.440 inches
• Outside Diameter: 6 inches
• Coupling Size: 9
• Axial Misalignment: 0.125 inches
• Maximum RPM: 3750 rpm
• Torque Rating (Max): 7200 in lb
• Temperature Range (Min): -65 °F
• Temperature Range (Max): 250 °F
• Wind-Up Angle @ Nominal Torque: 7 °
• Torsional Stiffness: 7500 inch pounds/radian
• Weight: 2.0 lb
• EAN or UPC: 685144407443
• Sleeve Type: H
• Insert Style: One Piece
