Lovejoy 68514445688 D8B Universal Joint 1.25 Outer Diameter (3/4 inches)

Product Description

The Lovejoy D8B universal joint, MPN 68514445688, connects two rotating shafts at angles up to twenty-five degrees. This joint is made of AISI 1144 carbon steel for enhanced durability and has a single pin-and-block configuration. Bored hubs on this joint can fit onto shafts without the need for machining.

• Single pin and block design for up to 25 degrees of angular misalignment.
• Operating temperature range of -30 to 212 degrees Fahrenheit.
• 1.25 outer diameter with a total length of 3.75 inches.

Product Highlights

This universal joint allows for the transmission of motion and torque between shafts, making it suitable for moderate torque applications such as compressors, fans, and machine tools.

Product Information

Standard Information

• Manufacturer: Lovejoy
• Model Number: 68514445688

Technical Specifications

• Bore Size: 0.625 inches diameter x 1.06 inches deep, 0.75 inches diameter x 1.06 inches deep
• Joint Diameter: 1.25 inches
• Overall Length: 3.75 inches
• Pin Height: 1.88 inches
• Maximum Misalignment Angle: 25 degrees
• Torque Rating: 5220 in-lb static
• Maximum Speed: 1750 RPM
• Material: Steel
• Finish: Metallic
