Lovejoy 68514415744 D4-UJ-SOLIDXSOLID 0.75 Universal Joint

Product Description

The Lovejoy universal joint model 68514415744 connects two rotating shafts. It accommodates angular misalignments up to twenty-five degrees. This joint is made from steel, providing durability and strength. It is suitable for various applications including fans, machine tools, and compressors.

• Designed for up to 25 degrees of angular misalignment
• Maximum operational speed of 1750 RPM
• Made of steel for high strength and machinability

Product Highlights

This universal joint offers a single pin and block design for stable operation. It has solid hubs that support custom machining.

Product Information

Standard Information

• MPN: 68514415744
• Manufacturer: Lovejoy

Technical Specifications

• Bore Size: 0.62 inches diameter x 0.88 inches deep
• Joint Diameter: 0.75 inches
• Maximum Misalignment Angle: 25 degrees
• Maximum Speed: 1750 RPM
• Overall Length: 2.68 inches
• Pin Height: 1.34 inches
• Torque Rating: 768 in-lb static
• Material: Steel
