Lovejoy 68514411512 L100 HUB 3/4 3/16X3/32 KW LOV

Product Description

The Lovejoy 68514411512 is a jaw coupling hub designed for performance and reliability. It features a three-quarter inch bore and meets the specifications for L100 coupling applications. This hub is made from sintered iron and has a diameter of two point five four inches. Additionally, it has a hub length of two point zero nine inches for effective coupling function.

• Fail-safe design maintains functionality even if elastomer fails
• No metal contact minimizes wear and tear
• Resistant to oil, dirt, moisture, and grease

Product Highlights

Engineered for versatility with more than 850,000 bore combinations, this coupling hub features a maximum speed of seven thousand RPM and a keyway size of three-sixteenth inch wide by three-thirty-seconds inch deep.

Product Information

Standard Information

• Brand: Lovejoy
• Manufacturer: Lovejoy

Technical Specifications

• MPN: 68514411512
• Bore Diameter: 3/4 in
• Coupling Size: L100
• Hub Diameter: 2.54 in
• Hub Length: 2.09 in
• Keyway Size: 3/16 in W x 3/32 in D
• Length Through Bore: 1.38 in
• Material: Sintered Iron
• Maximum Speed: 7000 RPM
• Screw Size: 5/16-18
• Finish: Metallic
• Country of Origin: US
