Locknetics CS750LBM32D Electric Strike 12/24V Latch Bolt Monitor

Product Description

The LOCKNETICS CS750LBM32D is a cylindrical electric strike designed for commercial and institutional door hardware applications. It operates on field-selectable 12 or 24 volt DC power, allowing the installer to configure voltage on-site without additional components. The strike features integrated latch bolt monitoring, which provides a dry-contact signal confirming latch position to an access control panel or alarm system. Two faceplate options are included — round and square — accommodating different door prep styles. Licensed access control and low-voltage technicians are the primary installers of this hardware.

The CS750LBM32D is suited for interior and perimeter doors in commercial, multi-family, and institutional buildings where electric latch retraction or fail-safe door control is required. The 3/4 inch latch bolt projection makes it compatible with standard cylindrical lockset preps. The latch bolt monitoring output integrates with access control systems, door position monitoring loops, and security management software to provide real-time door status.

Key Features

• Field-selectable 12 or 24 volt DC operation — no rewiring required when voltage changes on-site
• Integrated latch bolt monitoring for dry-contact status output to access control or alarm panels
• 3/4 inch latch bolt projection for standard cylindrical door prep compatibility
• Includes both round and square faceplates for flexible door hardware installation
• Compact form factor suited to hollow metal and wood door frames

Compatibility

Designed as an OEM-style replacement or new-installation electric strike for cylindrical lockset applications on commercial and institutional doors requiring 12 or 24 volt operation with latch bolt monitoring.

Installation Notes

Installation of electric strikes is typically performed by licensed low-voltage technicians or access control contractors in accordance with local electrical codes and NFPA 101 life safety requirements. Disconnect all power to the access control panel and door hardware circuit before beginning installation. Verify door frame prep dimensions and faceplate selection before securing the strike body, and confirm voltage selection on the field-selectable jumper or switch prior to restoring power. Do not force the latch bolt monitoring wires into terminals rated for higher-gauge conductors than the wire supplied.
