Locinox FORTIMA-SD-R Fortima SD-R Magnetic Latch for Pool and Park Gates (Round Posts)

Product Description

The Locinox FORTIMA-SD-R is a magnetic child-safe gate latch for single-leaf pool and park gates designed for round posts. It uses patented internal leverage and a strong magnet to ensure secure closing with push-down prevention. The latch provides full vertical adjustability and 1 inch horizontal adjustment with an operational gap of 3/8 inch to 1-3/8 inch and a 3/4 inch sag tolerance. Construction is anodized aluminum with powder-coated components and it is rekeyable to Schlage-C.

• Patented internal leverage with powerful magnetic closing; magnetic reach approximately 1-1/4 inch (30 mm) and push-down prevention.
• Adjustable and sag-proof: full vertical adjustability, 1 inch horizontal adjustment; operational gap 3/8 inch to 1-3/8 inch; 3/4 inch vertical tolerance.
• Durable construction: anodized aluminum housing with powder-coated components; tested to 2,000,000 cycles; rekeyable to Schlage-C keyway.

Product Highlights

Child-safe magnetic latch for single-leaf pool and park gates on round posts; adjustable, rekeyable, and weather resistant; tested to 2,000,000 cycles.

Product Information

Standard Information

• Brand: LOCINOX
• Manufacturer Part Number: FORTIMA-SD-R

Technical Specifications

• Brand: Locinox
• MPN: FORTIMA-SD-R
• Manufacturer Part Number: P00010976
• Model: FortiMa SD-R
• Application: Magnetic child-safe latch for single-leaf pool and park gates (round posts)
• Frame Type: Round posts (R)
• Compatible Gate Materials: Metal, vinyl, wooden gates
• Housing Material: Anodized aluminum
• Finish: Powder-coated components
• Magnetic Distance: 1-1/4 inch (approx. 30–31.75 mm)
• Adjustability: Full vertical adjustability; 1 inch horizontal adjustability
• Operational Gap Range: 3/8 inch to 1-3/8 inch (approx. 10 mm to 35 mm)
• Vertical Tolerance (Sag-proof): 3/4 inch
• Rekeyable: Schlage-C key-in-knob cylinder (5-pin, drilled 6-pin)
• Test Cycles: Tested up to 2,000,000 cycles
• Safety Feature: Push-down prevention — only opens when magnet is pulled up
• Weather Resistance: Anodized and powder-coated for extreme weather resistance
• Includes: Self-drilling screws for round frames
• Compliance: Meets most international pool gate code requirements
• Manufacturer: Locinox USA
