Lochinvar PVN05040 50 Gal Gas Water Heater Power Vent

Product Description

The Lochinvar PVN05040 is a residential power vented gas water heater with a capacity of fifty gallons. This model uses natural gas as fuel and has a BTU rating of fifty thousand. The tank is made from glass-lined steel, which adds durability.

• First hour recovery: ninety gallons
• Recovery rate: fifty-six gallons per hour at a ninety-degree rise
• Maximum pressure: three hundred PSI test and one hundred fifty PSI working

Product Highlights

This unit is suitable for residential applications, recognized for its efficiency, and meets industry standards.

Product Information

Standard Information

• Item Name: Gas Water Heater
• Type: Residential, Power Vented

Technical Specifications

• Capacity: 50 Gal
• Fuel Type: Natural Gas
• BTU Rating: 50000 BTU/HR
• Material: Glass-Lined Steel Tank
• First Hour Recovery: 90 Gal
• Recovery: 56 GPH at 90 Deg Rise
• Energy Factor: 0.7
• Maximum Pressure: 300 PSI Test, 150 PSI Working
• Gas Connection: 1/2 IN
• Water Connection: 3/4 IN
• Vent Size: 2, 3 Or 4 IN
• Diameter: 20 IN
• Height: 68-1/2 IN
• Height To Gas Connection: 13-1/4 IN
• Height To Valve Connection: 53-1/4 IN
• Height To Hot And Cold Water Connection: 59-1/4 IN
• Industry Standards: AHRI Certified, CSA Low Lead Content Certified, Energy Star Rated, NAECA Compliant, ASHRAE/IES 90.1
