Product Description
The Little Giant F40-5500 wet rotor pump is ideal for ponds up to 5500 gallons. This pump can be positioned vertically or horizontally and can be used submerged or outside the pond. It features an oil-free design for maximum safety for all pond life and includes a rope/cable loop for deep water retrieval and a pre-filter.
- Ideal for ponds up to 5500 gallons; 2-inch MNPT and SPIG discharge
- Includes 2 pre-screens with removable fastener to hold screen in place
- Can be positioned vertically or horizontally; can be used submerged or in-line
Product Highlights
The Little Giant wet rotor pump is designed for flexibility and durability in any decorative water application. It is constructed without a mechanical seal or oil for maximum safety for all pond life.
Product Information
Standard Information
-
Brand: LITTLE GIANT
-
Manufacturer Part Number: 566727
Technical Specifications
-
Amperage: 3.0 Amps
-
Wattage: 360 Watts
-
Cord Length: 20 ft
-
Discharge and Inlet: 2" MNPT and SPIG
-
Maximum Flow Rate: 91 Gallons Per Minute
-
Shut-off: 21.3 ft
-
Voltage: 115 V
-
Frequency: 60 Hz
-
Discharge: 2 "
-
Suction: 2 "
-
Suction Type: MNPT
-
Product Length: 13.25 "
-
Product Width: 6.1 "
-
Product Height: 8 "
-
Pump Length: 13.25 "
-
Mounting Type: Horizontal Vertical
-
Overload Protection: Thermal
-
Flow Rate: 5550 gph
-
Maximum Lifting Height: 21.3 Feet
-
Intake and Discharge Size: 2" MNPT
-
Performance at 0' lift: 5,540 gph (20,971 lph)
-
Performance at 1' lift: 5,255 gph (19,892 lph)
-
Performance at 5' lift: 4,235 gph (16,031 lph)
-
Performance at 10' lift: 2895 gph (10,959 lph)
-
Performance at 15' lift: 1955 gph (7,400 lph)
-
Performance at 20' lift: 415 gph (1570 lph)
-
Shutoff Head (ft.): 21.3'
-
Amps - Full Load: 3 A
-
Full Load Watts: 360 W
-
Volts: 115 VAC
