Littelfuse TSU2000 UNI-TIME 24 to 240 VAC Adjustable External Relay

Product Description

The Littelfuse TSU2000 is an adjustable external time delay relay designed for various applications. It operates on a voltage range of twenty-four to two hundred forty volts AC. This relay features a solid-state design, ensuring durability and reliability.

• Universal AC/DC operating voltage for flexibility
• Solid-state construction for long life and resistance to wear
• Simple two terminal series connection for easy installation

Product Highlights

This device is suitable for use in HVAC systems, industrial automation, and any installation requiring a reliable time delay mechanism.

Product Information

Standard Information

• Brand: Littelfuse
• MPN: TSU2000

Technical Specifications

• Contact Form: SPDT/NO (1 Form A)
• Dimensions: 2 inches H x 2 inches W x 1.21 inches D
• Electrical Connections: Male Quick-Connect Terminal
• Mounting Type: Surface
• Operation Mode: Delay On Make
• Series: TSU2000
• Temperature Rating: -20 to 70 degrees F
• Time Setting: 5 to 480 seconds
• Voltage Rating: 24 to 240 VAC
• Manufacturer: Littelfuse
