LITTELFUSE ORB120A25 TIME DELAY RELAY SPDT 120 VAC ADJUSTABLE 3 TO 300 S

Product Description

The Littelfuse ORB120A25 Time Delay Relay provides precise control with adjustable delay settings ranging from three to three hundred seconds. This relay is perfect for applications requiring a specific time delay to ensure safety or functional requirements in industrial automation and process control systems.

• Adjustable delay settings suitable for a wide range of applications.
• High reliability and repeat accuracy of plus or minus two percent.
• Supports loads for both AC or DC voltages with isolated, 10 A, SPDT or DPDT output contacts.

Product Highlights

This relay operates in a delay on break mode which begins timing when the initiate switch is opened and maintains output during timing. It is equipped with male quick-connect terminals for easy installation.

Product Information

Standard Information

• Mounting Type: Surface
• Temperature Rating: -20 to 65 degrees Fahrenheit

Technical Specifications

• Operation Mode: Delay On Break
• Dimensions: 2.12 in H x 3.69 in W x 1.88 in D
• Input Voltage: 120 VAC
• Output Type: Electromechanical relay
• Time Setting: 3 to 300 seconds
• Electrical Connections: Male Quick-Connect Terminal
