Littelfuse NLN020 LFSE NLN020 FUS 250V O/T CLASS K5 2

Product Description

The Littelfuse NLN020 is a fast-acting one-time fuse rated at twenty amperes and two hundred fifty volts. This fuse is designed to protect general-purpose feeder and branch circuits where available short circuit currents are less than fifty thousand amperes. It serves as a replacement for all Class H fuses with a ten thousand ampere interrupting rating. The NLN series fuses are suitable for residential and smaller commercial applications.

• Provides low-cost protection for general-purpose circuits.
• Interruption rating of fifty thousand amperes.
• Uses ferrule terminal type for standard fits.

Product Highlights

Efficient and reliable protection for circuits meeting the needs for residential or light industrial use.

Product Information

Standard Information

• Brand: Littelfuse
• MPN: NLN020

Technical Specifications

• Type: Class K5
• Voltage: 250 Volt
• Amperage: 20 Amp
• Interrupting Rating: 50000 Ampere (Symmetrical), 20000 Ampere (DC)
• Diameter: 0.56 inches
• Body Size: 9/16 inches by 2 inches
• Frequency Rating: 50/60 Hz
• Terminal Type: Ferrule
