Littelfuse LLNRK015 POWR-GARD Time Delay Fuse 15 A 250 VAC/125 VDC 200/20 kA

Product Description

The Littelfuse LLNRK015 is a Time Delay Fuse designed for applications requiring reliable overload protection. This fuse is rated at 15 amperes and operates at 250 VAC and 125 VDC. It features a dual element construction and is approved for use in Class RK1 circuits. The LLNRK015 fuse is suitable for service entrance, main, feeder, and general-purpose branch circuits, providing superior protection from overloads and short circuits.

• Current Limiting Design
• Time Delay Feature
• 200 kA Interrupt Rating

Product Highlights

Provides excellent protection for various electrical circuits. Ideal for upgrading systems in need of enhanced safety measures while minimizing downtime.

Product Information

Standard Information

• Manufacturer: Littelfuse
• Catalog Number: LLNRK015

Technical Specifications

• Amperage Rating: 15 A
• Voltage Rating: 250 VAC / 125 VDC
• Interrupt Rating: 200 kA at 250 VAC, 20 kA at 125 VDC
• Terminal Type: Ferrule
• Material: Melamine
• Body Size: 9/16 inches Diameter x 2 inches Length
• Mounting Type: Holder
• Standards/Approvals: UL 248-12, CSA LR29862
