LITTELFUSE L50S150 VERY FAST-ACTING SEMICONDUCTOR FUSE 150 A

Product Description

The LITTELFUSE L50S150 is a very fast-acting semiconductor fuse designed for high-speed protection in electrical systems. This fuse has a rating of 150 amperes and operates at a voltage of five hundred VAC and four hundred fifty VDC. Its high interrupt rating of two hundred kA makes it suitable for various applications, including AC and DC drives, power converters, and UPS systems.

• Indicating type for quick identification of blown fuses
• Constructed of fiberglass for durability
• Designed for bolt mounting with blade terminal connection

Product Highlights

This fuse is essential for protecting electrical circuits from overloads and short circuits. It features a controlled transient overvoltage protection, making it ideal for sensitive equipment.

Product Information

Standard Information

• Manufacturer: LITTELFUSE
• Series: L50S

Technical Specifications

• Amperage Rating: 150 A
• Body Size: 1-7/32 inches diameter x 3-5/8 inches length
• Body Type: Traditional/Round
• Indicating/Non-Indicating: Indicating
• Interrupt Rating: 200/20 kA
• Material: Fiberglass
• Mounting Type: Bolt
• Terminal Type: Blade
• Voltage Rating: 500 VAC/450 VDC
• Type: Very Fast Acting High Speed
