LITTELFUSE L15S400 VERY FAST-ACTING SEMICONDUCTOR FUSE 400 A 150 VAC/100 VDC

Product Description

The LITTELFUSE L15S400 is a very fast-acting semiconductor fuse designed for high-speed applications. This fuse has an amperage rating of four hundred amperes and is suitable for use in circuits rated at one hundred fifty volts AC and one hundred volts DC. It features a blade terminal, bolt mounting, and is made of fiberglass with a round body measuring one inch in diameter by two and twenty-six thirty-seconds inches long.

• High-speed response to overcurrent events
• Indicating type for easy status monitoring
• Low watts loss for efficient operation

Product Highlights

This fuse is ideal for protecting sensitive semiconductor devices, including SCRs, diodes, thyristors, and transistors. It is rated for a controlled transient over-voltage and demonstrates extremely low I2T let-through energy.

Product Information

Standard Information

• Manufacturer: LITTELFUSE
• Type: Very Fast Acting High Speed

Technical Specifications

• Amperage Rating: 400 A
• Voltage Rating: 150 VAC / 100 VDC
• Interrupt Rating: 100/20 kA
• Body Size: 1 in Dia x 2-21/32 in L
• Body Type: Round
• Indicating/Non-Indicating: Indicating
• Material: Fiberglass
• Mounting Type: Bolt
• Terminal Type: Blade
• Series: L15S
