Littelfuse KLKR006 Class CC Fast-Acting Fuse 6 Amp 600VAC 300VDC

Product Description

The Littelfuse KLKR006 is a Class CC fast-acting fuse with a 6 Amp rating. It operates at 600V AC and 300V DC, designed for reliable protection of circuits in various applications. This fuse is ideal for protecting electrical systems by quickly interrupting the flow of current in case of overloads or short circuits.

• Compact size for easy installation in tight spaces
• Fast-acting response suitable for sensitive electronic equipment
• High interrupting capacity of 200,000 amperes

Product Highlights

The KLKR006 provides dependable protection for industrial control systems, power distribution setups, and motor protection applications. Its fast-acting nature and high interrupting capacity prevent damage from electrical faults.

Product Information

Standard Information

• Manufacturer: Littelfuse
• Brand: Littelfuse
• Series: KLKR
• Class: CC
• Country of Origin: Mexico

Technical Specifications

• Ampere Rating: 6 Amps
• Voltage Rating: 600 Volts AC / 300 Volts DC
• Interrupt Rating: 200,000 Amps at 600VAC, 20,000 Amps at 300VDC
• Body Type: Cartridge
• Body Size: 13/32 inches Diameter x 1-1/2 inches Length
• Material: Melamine
• Mounting Type: Holder
• Response Time: 12 seconds
• Terminal Type: Ferrule
• Approvals: UL 248-8, CSA Certified, RoHS
• UPC: 079458260588
