Littelfuse KLK015 Fast-Acting Midget Fuse 600V 15 A

Product Description

The Littelfuse KLK015 is a fast-acting, high-interrupting capacity fuse designed for reliable protection in electrical circuits. Rated for 15 Amps and capable of handling voltages up to six hundred volts AC and five hundred volts DC, this fuse serves as a crucial component in control circuits, street lighting, and sensitive electronic applications.

• Fast-acting response for quick fault interruption
• Suitable for multiple applications, including street lighting and computers
• RoHS compliant and UL approved for safety

Product Highlights

This fuse is especially suited for applications that do not encounter high inrush currents. Its cylindrical design allows for easy installation in clips or panels.

Product Information

Standard Information

• Brand: Littelfuse
• MPN: KLK015

Technical Specifications

• Catalog Number: KLK015
• Voltage Rating: 600 VAC / 500 VDC
• Amperage Rating: 15 A
• Interrupt Rating: 100 kA @ 600 VAC, 50 kA @ 500 VDC
• Body Size: 1.5 inches long x 0.406 inches diameter
• Application: Control circuits, street lighting, computers, small motors
• Material: Melamine
• Mounting Type: Clip
• Response Time: Fast-acting
