Littelfuse JLLS125 125 Amp Fuse 600VAC 300VDC Class T Fast-Acting

Product Description

The Littelfuse JLLS125 fuse offers reliable fast-acting protection in electrical systems, ideal for industrial applications. With a 125 ampere rating and compatibility with both 600VAC and 300VDC, this class T fuse is designed for robust performance in variable speed drives and motor protection circuits.

• Fast-acting design for immediate response under fault conditions
• Compact form factor for space-efficient installation
• High interrupt rating up to 200kA at 600VAC and 20kA at 300VDC ensures safety and system integrity

Product Highlights

The JLLS125 is crafted from durable melamine with a knife blade terminal for secure and reliable connections. Its non-indicating style supports straightforward implementation into existing setups without the need for additional indicators.

Product Information

Standard Information

• Brand: Littelfuse
• UPC: 079458190847

Technical Specifications

• Mounting Type: Holder
• Body Type: Cartridge
• Dimensions: 1.078 inches diameter x 3.25 inches length
• Material: Melamine
• Interrupt Rating: AC: 200kA, DC: 20kA
• Standard: UL 248-15, CSA Certified
