Littelfuse JLLS1000 Space-saving Class T Fuse 1000A 600V Class T

Product Description

The Littelfuse JLLS1000 is a Class T fast-acting fuse designed for overload and short circuit protection. With a current rating of one thousand amperes and a voltage rating of six hundred VAC/three hundred VDC, this fuse is suitable for various applications including variable speed drives. Its compact design allows for installation in tight spaces and reduces the area required compared to traditional Class R fuses.

• Fast-acting overload protection
• Current limiting design
• Compact size ideal for space-constrained installations

Product Highlights

This fast-acting fuse ensures reliable interruption of overcurrents while protecting sensitive equipment from damage.

Product Information

Standard Information

• Catalog Number: JLLS1000
• Manufacturer: Littelfuse

Technical Specifications

• Rated Amperage: 1000 A
• Voltage Rating: 600 VAC/300 VDC
• Interrupt Rating: 200000 Ampere (Symmetrical)
• Body Type: Cartridge
• Standard: UL 248-15, CSA
• Material: Melamine
• Diameter: 2.625 inches
• Length: 5.271 inches
