Littelfuse FLSR050 50 Amp 600 VAC 300 VDC Class RK5 Dual Element Time Delay Fuse

Product Description

The Littelfuse FLSR050 50 Amp 600 VAC 300 VDC Class RK5 Dual Element Time Delay Fuse from Littelfuse offers superior protection for your electrical circuits, including those with motors.

• Reliable 50 Amp fuse with 600 VAC and 300 VDC ratings
• Ideal for industrial and general-purpose circuits
• UL Class RK5 rating ensures enhanced safety

Product Highlights

Known for its time-delay feature, the Littelfuse FLSR050 ensures protection even under heavy current surges, making it an ideal choice for various demanding applications.

Product Information

Standard Information

• Brand: Littelfuse
• MPN: FLSR050

Technical Specifications

• Amperage Rating: 50 A
• Voltage Rating: 600 VAC/300 VDC
• Class: RK5
• Element: Dual
• Interrupt Rating: 200 kA at 600VAC, 20 kA at 300VDC
• Body Size: 1-1/16 in Dia x 5-1/2 in L
• Mounting Type: Holder
• Material: Composite
• Response Time: 10 s
• Frequency Rating: 50/60 Hz
• Terminal Type: Ferrule
• Standards/Approvals: UL 248-12, CSA LR29862, Federal Specification WF-1814
