Littelfuse FLSR007 Time Delay Fuse 600V 7A Class RK5 Dual Element

Product Description

The Littelfuse FLSR007 fuse is engineered for reliable circuit protection. With a 7 amp rating and dual element design, it's ideal for industrial and commercial applications.

• Time delay feature allows passing of harmless inrush currents without opening.
• Rated for 600V AC/300V DC, supporting high voltage applications.
• Constructed from durable materials, ensuring longevity and reliability.

Product Highlights

This cylindrical, fiberglass body fuse measures 5 inches in length and 13/16 inches in diameter, equipped to handle interrupt ratings up to 200kA at 600V AC and 20kA at 300V DC. Its class RK5 compliance meets rigorous safety standards.

Product Information

Standard Information

• Brand: Littelfuse
• MPN: FLSR007

Technical Specifications

• Voltage Rating: 600V AC, 300V DC
• Amperage Rating: 7A
• Interrupt Rating: 200/20 kA
• Response Time: 10s
• Material: Fiberglass
• Mounting Type: Holder
• Dimension: 5 in Length x 13/16 in Diameter
• Compliance: UL 248-12, CSA LR29862
