Littelfuse FLNR090ID FUSE - FLNR 90A CLASS RK5 DUAL ELEMENT TIME DELAY INDICATION

Product Description

The Littelfuse FLNR090ID is a 90 Amp class RK5 dual element time delay fuse designed for reliable circuit protection. This fuse operates at a voltage rating of 250 VAC and 125 VDC. The built-in indicator enables quick visual identification of blown fuses, reducing downtime.

• Reliable time delay function for consistent performance.
• Indicates fuse status through a visible window.
• Adheres to UL 248-12 standards for safety and reliability.

Product Highlights

Designed for applications requiring safety and efficiency. Ideal for service entrance switches, motor control centers, and various industrial settings.

Product Information

Standard Information

• Manufacturer: Littelfuse
• Part Number: FLNR090ID

Technical Specifications

• Type: Class RK5
• Amperage: 90 A
• Voltage Rating: 250 VAC / 125 VDC
• Interrupt Rating: 200000 A (symmetrical), 20000 A (DC)
• Body Type: Cylindrical
• Response Time: 10 s
• Dimensions: 1.06 in diameter x 5.56 in length
