Littelfuse FLNR015 Time Delay Fuse 250V 15 Amp Class RK5

Product Description

The Littelfuse FLNR015 fuse is engineered for reliable performance, featuring a time-delay function ideal for systems with motors. This fuse provides advanced protection against short circuits and overloads, with a dual-element design that enhances its operational integrity in demanding environments.

• Time Delay Feature allows temporary surge pass without tripping.
• Dual-Element construction for enhanced protection.
• Class RK5 rating ensures suitability for a wide range of industrial applications.

Product Highlights

Utilizing a cylindrical body, this fuse is easily installable in standard fuse holders. It is designed to operate smoothly in both AC and DC circuits, providing consistent performance. The fiber material construction complements its robust design, making it suitable for general-purpose applications, including motor protection and switchboard main feeds.

Product Information

Standard Information

• Brand: Littelfuse
• Model: FLNR015

Technical Specifications

• Amperage Rating: 15 Amp
• Voltage Rating: 250 VAC/125 VDC
• Interrupt Rating: 200/20 kA
• Response Time: 10 s
• Mounting Type: Holder
• Terminal Type: Ferrule
• Body Size: 9/16 in Diameter x 2 in Length
• Material: Fiber
• Standards/Approvals: UL 248-12, CSA LR29862, Federal Specification WF-1814
