Littelfuse FLNR01.6 LITTELFUSE 1-6/10A DELAY 250AC/125DC CLASS RK5 FUSE

Product Description

The Littelfuse POWR-GARD FLNR01.6 is a time delay fuse designed for use in various electrical applications. This current limiting fuse provides a rating of 1.6 amperes, compatible with both 250 VAC and 125 VDC systems. The fuse features a 200/20 kA interrupt rating and is classified as RK5, specifically made for motor and general purpose circuits.

• Reliable interruption of all over currents up to 200 kA
• Faster acting short circuit protection
• Automated precision manufacturing for consistent overload responses

Product Highlights

Ideal for service entrance switches, transformers, and motor control circuits.

Product Information

Standard Information

• Manufacturer: Littelfuse
• MPN: FLNR01.6

Technical Specifications

• Amperage Rating: 1.6 A
• Voltage Rating: 250 VAC / 125 VDC
• Body Size: 9/16 inches Diameter x 2 inches Length
• Body Type: Cylindrical
• Class: RK5
• Element: Dual
• Response Time: 10 seconds
• Terminal Type: Ferrule
• Application: Service Entrance Switches, Transformers, Motor Control, General Circuits
• Standards/Approvals: UL 248-12, CSA LR29862
