Littelfuse FLNR002 Fuse 250V Time Delay 2A

Product Description

The Littelfuse FLNR002 is a cylindrical time-delay fuse, rated for 250V and 2A, designed to provide reliable overcurrent protection. This fuse features a dual-element design, ideal for circuits that require time delay characteristics to handle temporary overload conditions without tripping unnecessarily.

• Offers reliable protection up to 200kA interrupt rating at 250VAC.
• Dual-element, cylindrical body made of fiberglass for robustness.
• Non-indicating time-delay feature allows for short-duration overcurrent conditions.

Product Highlights

This fuse is particularly suited for applications like service entrance switches and motor control circuits, ensuring safety and continuity in electrical systems. Its design and build are compliant with UL 248-12 and CSA standards for safety and reliability.

Product Information

Standard Information

• Brand: Littelfuse
• MPN: FLNR002
• Series: FLNR
• Class: RK5

Technical Specifications

• Voltage Rating: 250VAC/125VDC
• Amperage: 2A
• Interrupt Rating: 200kA at 250VAC, 20kA at 125VDC
• Body Material: Fiberglass
• Dimensions: 2 inches Length x 9/16 inches Diameter
• Mounting Type: Holder
• Terminal Type: Ferrule
