Littelfuse FLM009 Use FLM 250 volt time-delay fuses 9 A

Product Description

Littelfuse FLM009 is a time-delay fuse designed for protecting control circuit transformers and solenoids. This fuse is ideal for circuits with high inrush currents. It provides excellent supplemental protection for small motors. The fuse operates at a voltage rating of two hundred fifty volts with a current rating of nine amps.

• Time-delay feature for high inrush applications
• Protects control circuits and small motors
• Ten kA interrupt rating for safe operation

Product Highlights

This Littelfuse product ensures reliability and safety for various electrical applications.

Product Information

Standard Information

• Manufacturer: Littelfuse
• UPC: 079458140644

Technical Specifications

• Catalog Number: FLM009
• Voltage Rating: 250 VAC/125 VDC
• Amperage Rating: 9 A
• Interrupt Rating: 10 kA
• Body Size: 13/32 inches diameter x 1-1/2 inches length
• Type: Time Delay
• Terminal Type: Ferrule
• Application: Supplemental protection for control circuits
