Littelfuse FLM.300 Time Delay Midget Fuse 0.3 Amp 250 VAC 125 VDC

Product Description

The Littelfuse FLM.300 Time Delay Midget Fuse is essential for enhancing circuit safety in environments with high inrush currents. Primarily used in control circuits, this fuse offers reliable performance with a nominal amperage of 0.3 and a dual voltage rating of 250 VAC and 125 VDC. It is designed to protect transformers, solenoids, and small motors, ensuring secure and sustained operations.

• Effective in shielding control circuits from unexpected surges.
• Optimal for circuits requiring supplemental motor protection.
• Suitable for applications demanding a delay timing to manage inrush currents effectively.

Product Highlights

Littelfuse's FLM series fuses are renowned for their precision and reliability in protecting electrical circuits from high inrush currents and overloads.

Product Information

Standard Information

• Brand: Littelfuse
• Category: Power Distribution - Fuses - Midget Fuses

Technical Specifications

• Amperage: 0.3 Amp
• Voltage: 250 VAC / 125 VDC
• Time-Delay Configuration: Ensures protection against temporary spikes without tripping.
• Interrupt Rating: 10 kAIC
• Dimensions: 13/32 inch diameter x 1-1/2 inch length
• Compliance: RoHS Compliant, CA Prop65 Warning for Nickel
