Littelfuse FLA002 Time Delay Pin Indicating Fuse 125 VAC

Product Description

The Littelfuse FLA002 is a time-delay pin indicating fuse rated for one hundred twenty-five volts. This fuse protects control circuit transformers, solenoids, and circuits with high inrush currents. The metal indicating pin pops out when the fuse opens, providing a visual indication of an open fuse. This fuse is designed for use in combination with specialized fuse blocks to operate mechanical signal switches or energize alarm circuits. Fuses rated twelve amperes and above incorporate dual-tube construction.

• Time-delay function for controlled current protection.
• Visual indication when fuse is blown.
• Compatible with fuse blocks for added functionality.

Product Highlights

This fuse is suitable for controlling various electrical applications, providing enhanced safety and monitoring through mechanical signal indications.

Product Information

Standard Information

• Catalog Number: FLA002
• Manufacturer: Littelfuse

Technical Specifications

• Current Rating: 2 A
• Voltage Rating: 125 VAC
• Interrupt Rating: 10 kA
• Response Time: 5 s
• Body Type: Cylindrical
• Body Size: 13/32 inch diameter x 1.5 inches length
• Terminal Type: Ferrule
• Mounting Type: Clip
