LITTELFUSE ERDM427 ECONO-TIMER Time Delay Relay 120 VAC

Product Description

The Littelfuse ERDM427 Econo-Timer is a precision timing solution designed for robust industrial applications, featuring adjustable timing and reliable performance.

• Adjustable delay setting from 0.1 to 5 minutes.
• Durable design withstands harsh environments from -40 to 65 degrees Fahrenheit.
• DPDT/NO-NC contact form ensures versatile load control.

Product Highlights

This timer includes an easy adjustment knob and quick-connect terminals making installation straightforward. Its solid-state construction increases stability and lifespan.

Product Information

Standard Information

• Brand: Littelfuse
• MPN: ERDM427

Technical Specifications

• Operating Mode: Delay On Make
• Voltage Rating: 120 VAC
• Contact Form: DPDT/NO-NC (2 Form C)
• Dimensions: 3.5 in H x 2.5 in W x 1.7 in D
• Temperature Range: -40 to 65 degrees Fahrenheit
• Mounting Type: Surface
• Electrical Connections: Male Quick-Connect Terminal
• Time Setting: 0.1 to 5 min
