Littelfuse AR120A-3095 Alternating Relay 120V

Product Description

The Littelfuse AR120A-3095 Alternating Relay is a robust component suitable for various industrial applications. This relay enhances system efficiency through its compact alternating relay technology.

• Ensures efficient and dependable operation
• Handles a wide range of voltages
• Features fast switching speed

Product Highlights

This relay is designed for durable performance in harsh environments, making it ideal for industrial use. It supports three-phase power systems, providing flexibility and precise switching operations.

Product Information

Standard Information

• Brand: Littelfuse
• MPN: AR120A-3095

Technical Specifications

• Input Voltage: 24, 120, or 230VAC
• Input Tolerance: 24VAC: -15% - 20%; 120 and 230VAC: -20% - 10%
• AC Line Frequency: 50/60Hz
• Maximum Output Voltage: 250VAC
• Output Type: Electromechanical Relay
• Output Form: SPDT, DPDT cross-wired DPDT
• Output Load Rating: 10A resistive @ 120/240VAC and 28 VDC; 1/3hp @ 120 / 240VAC
• Isolation Voltage (V): 1500V RMS input to output
• Life: Mechanical - 1 x 10^7; Electrical - 1 x 10^6
• Termination Type: Octal 8-pin or magnal 11-pin
• Mounting Method: Plug-in socket
• Operating Temperature: -20°C to 60°C (-4°F to 140°F)
• Storage Temperature: -30°C to 85°C (-22°F to 185°F)
• Dimensions: 3.20 x 2.39 x 1.78 inches (81.3 x 60.7 x 45.2mm)
