Littelfuse 218002P Powr-Gard Slo-Blo Cartridge Fuse 2 A 250 VAC (5 x 20 mm) 0218002.VXP

Product Description

Littelfuse 218002P is a Powr-Gard Slo-Blo time-lag cartridge fuse rated 2 A at 250 VAC. The miniature 5 x 20 mm glass body includes ferrule terminals for holder mounting, Class RK5 construction, and a 35 A interrupting rating at 250 VAC. Defined opening time characteristics range from 60 min at 150% to 0.02 to 0.3 s at 1000%; operating temperature is -55 to 125 C. The part meets IEC 60127-2 sheet 3 and applicable UL/CSA/CE standards.

• Time-lag (slo-blo) fuse, 2 A at 250 VAC with 35 A interrupting rating
• 5 x 20 mm glass cartridge body, ferrule terminals, holder mounting, Class RK5
• Defined time-current response (60 min at 150% to 0.02-0.3 s at 1000%), operating -55 to 125 C; IEC/UL/CSA/CE approvals

Product Highlights

Miniature 5 x 20 mm time-lag fuse for general-purpose and supplementary circuit protection

Product Information

Standard Information

• Brand: LITTELFUSE
• Manufacturer Part Number: 218002P
• Country of Origin: Mexico
