Lionbeam lb-b2022-b Motorized 4-in-1 Ir Ball Camera

Product Description

The LIONBEAM lb-b2022-b is a motorized ball-style security camera designed for flexible surveillance coverage in a wide range of installations. It features a 2.8-12mm motorized varifocal lens that allows remote zoom and focus adjustment, eliminating the need for physical access to the camera during setup. The lb-b2022-b supports four video formats: AHD, TVI, CVI, and analog, making it compatible with a broad range of existing DVR-based surveillance systems. Built-in infrared illumination provides clear video in low-light and nighttime conditions. The black housing is rated for both indoor and outdoor deployment.

This camera is suited for commercial, residential, and institutional surveillance applications where coverage flexibility and format compatibility are priorities. The motorized lens simplifies installation in locations that are difficult to access after mounting, such as high ceilings, exterior soffits, or enclosed enclosures. It is a practical choice for integrators managing mixed-format analog or hybrid DVR systems that require a single camera to serve multiple layout scenarios without changing hardware.

Key Features

• 2.8-12mm motorized varifocal lens with remote zoom and focus control
• Supports AHD, TVI, CVI, and analog video formats (4-in-1)
• Built-in infrared illumination for low-light and nighttime imaging
• Sleek ball-style housing suitable for indoor and outdoor use
• Remote lens adjustment reduces installation time and physical access requirements

Compatibility

Designed for use with DVR-based surveillance systems supporting AHD, TVI, CVI, or standard analog video formats.

Installation Notes

Installation is typically performed by a licensed security systems integrator or low-voltage technician. Power down the surveillance system before wiring or mounting the camera. Secure the ball housing to a structurally sound surface rated for the camera weight, and verify weatherproofing at all conduit or cable entry points for outdoor installations. Confirm DVR channel format settings match the selected output format of the camera before completing setup.

Technical Specifications

• Lens: 2.8-12mm motorized varifocal
• Supported Video Formats: AHD, TVI, CVI, Analog
• IR Illumination: Built-in
• Housing Color: Black
• Installation Environment: Indoor and Outdoor

Standard Information

• Brand: LIONBEAM
• Manufacturer Part Number: lb-b2022-b
