Link-Seal LS-200-S Link Seal, Stainless Steel

Product Description

The LINK-SEAL LS-200-S is a modular seal designed for sealing cylindrical objects through concrete walls, featuring stainless steel hardware. These seals provide a fast and affordable way to seal pipes passing through walls, floors, and ceilings. Made with durable EPDM black rubber, it handles temperatures up to 175 degrees F and provides a positive hydrostatic seal.

• Install in up to 75% less time compared to lead-oakum joints, hand-fitted flashings, mastics, or casing boots.
• Rated at 20 psig (40ft of head), which exceeds the performance requirements of most applications.
• Designed for use as a permanent seal with seal elements compounded to resist aging and attack from ozone, sunlight, water, and a wide range of chemicals.

Product Highlights

The LS-200-S Link Seals are ISO approved and help protect against corrosion, extend the life of the seal, and save time and money.

Product Information

Standard Information

• Brand: LINK-SEAL
• Manufacturer Part Number: LS-200-S

Technical Specifications

• MPN: LS-200-S
• Manufacturer: Link Seal
• Material: Stainless Steel
• Seal Material: EPDM
• Hardware Material: S316 Stainless Steel and Zinc Dichromate Coated Steel
• Pressure resistance: 20psig (40 ft of head)
