Lift-all EN2601DX5 Endless Sling 4800 Lb 1 in X 5 Ft Polyester

Product Description

The LIFT-ALL EN2601DX5 is a Type 5 endless round sling engineered for rigging applications where a continuous-loop configuration is required. Constructed from polyester webbing with a 2-ply build, it delivers a vertical working load limit of 4,800 pounds, a choker rating of 3,800 pounds, and a basket rating of 9,600 pounds. The yellow polyester core and cover provide abrasion resistance and allow for visual load-limit identification in the field. At 1 inch wide and 5 feet in length, this sling suits medium-duty lifting tasks where a compact, lightweight loop is needed. Licensed riggers and crane operators are the primary installers.

This sling is suited for construction, manufacturing, and maintenance environments where loads must be lifted in vertical, choker, or basket hitches. The endless loop design eliminates metal end fittings, reducing the risk of load damage on finished or fragile surfaces. It is well-matched to overhead lifting with cranes, hoists, and beam trolleys in both shop and field settings. The polyester construction resists moisture and many common shop chemicals, making it practical for use in light industrial and mechanical maintenance applications.

Key Features

• Vertical WLL of 4,800 lb, choker WLL of 3,800 lb, and basket WLL of 9,600 lb
• Type 5 endless loop construction eliminates hook-and-eye hardware contact with the load
• 2-ply polyester build provides abrasion resistance and consistent flexibility
• Rated for use up to 200 degrees F maximum operating temperature
• Yellow color coding aligns with industry WLL identification standards
• Compliant with OSHA 1910.184, ASME B30.9, and WSTDA standards

Compatibility

Designed as a general-purpose endless rigging sling compatible with standard crane hooks, shackles, and hoist rings used in vertical, choker, and basket hitch configurations.

Installation Notes

Rigging slings must be installed and inspected by a qualified rigger in accordance with OSHA 1910.184 and ASME B30.9. Inspect the sling for cuts, abrasion, UV degradation, or chemical damage before each lift. Never exceed the rated working load limit for the hitch type in use. Remove the sling from service immediately if any damage, discoloration, or deformation is observed.
