Lift-all EN1801TX10 Endless Sling 1.60 Ton 1in 10ft

Product Description

The LIFT-ALL EN1801TX10 is a Type 5 endless round sling constructed from polyester and rated for 1.60 tons (3,200 pounds) in a vertical hitch configuration. At 1 inch wide and 10 feet in length, this single-ply sling features a twisted eye design and is built to meet the load handling demands of rigging professionals across industrial, construction, and maintenance applications. The polyester construction provides abrasion resistance and a maximum working temperature of 200 degrees F. The gray and blue color coding assists with quick load rating identification on the job site.

This sling is suited for vertical, choker, and basket hitch configurations in light to medium rigging work. The choker hitch capacity is 2,500 pounds. Its compact 1 inch width makes it appropriate for loads where a narrow contact footprint is required, such as finished surfaces or confined anchor points. Riggers, millwrights, and ironworkers will find this sling appropriate for single-leg lifts in shop, warehouse, and field environments where a lightweight, synthetic sling is preferred over wire rope or chain.

Key Features

• 1.60 ton (3,200 lb) vertical rated capacity with twisted eye configuration
• 2,500 lb choker hitch capacity for angled load control
• Single-ply polyester construction with abrasion-resistant properties
• Rated for use up to 200 degrees F continuous working temperature
• Compliant with OSHA 1910.184, ASME B30.9, and WSTDA standards
• Gray and blue color coding for fast load rating identification

Compatibility

Designed as a standard endless round sling for single-leg vertical and choker hitch rigging applications requiring a 1 inch wide, 10 foot polyester sling rated to 1.60 tons vertical capacity.

Installation Notes

This sling should be installed and used by qualified riggers familiar with ASME B30.9 and OSHA 1910.184 requirements. Inspect the sling for cuts, abrasion, chemical damage, and UV degradation before each use, and remove from service immediately if any core or cover damage is found. Never exceed the rated load capacity for the hitch type in use, and ensure contact points do not create sharp-edge loading that could cut the sling cover. Store away from direct sunlight, heat sources, and chemical exposure when not in use.
