Lift-all 30008 Chain Sling 14 Ft Grade 100 12000 Lb

Product Description

The LIFT-ALL 30008 is a Grade 100 alloy steel chain sling designed for industrial lifting applications. It features a control plate and grab hook configuration and measures 14 feet (168 inches) in leg length. The 1/2-inch alloy steel chain carries a vertical capacity of 12,000 pounds and a capacity at 60 degrees of 20,800 pounds. Hardware is also alloy steel for consistent strength throughout the assembly. A yellow powder coat finish aids in visual identification on the job site. This sling is installed by riggers, millwrights, and qualified lifting personnel in manufacturing, construction, and heavy industrial environments.

This sling is suited for overhead lifting in industrial and commercial settings where high-capacity, single-leg chain rigging is required. The grab hook end fitting allows for quick connection to load attachment points. The control plate master link accommodates overhead cranes, hoists, and other rated lifting equipment. At 52 pounds, it is built for repeated heavy-duty use rather than light occasional lifts.

Key Features

• Grade 100 alloy steel chain provides high strength-to-weight ratio for demanding lifts
• 12,000 lb vertical capacity and 20,800 lb capacity at 60 degrees
• 1/2-inch chain size with 14-foot (168-inch) leg length
• Control plate and grab hook configuration for secure load attachment
• Yellow powder coat finish for job-site identification and abrasion resistance
• Meets OSHA, ASME B30.9, and NACM standards

Compatibility

Designed for use with overhead cranes, hoists, and rated lifting equipment that accepts Grade 100 alloy steel chain slings with a control plate master link and grab hook end fitting.

Installation Notes

Installation and rigging must be performed by a qualified rigger in accordance with OSHA regulations and ASME B30.9 standards. Inspect the sling for damage, cracks, or deformation before each use and remove from service if any defects are found. Never exceed the rated load capacity for the sling angle being used. Ensure all hooks are fully seated and latched on load attachment points before initiating any lift.
