Lew Electric PUFP-CT-WT-PB Square Kitchen Countertop Pop-Up GFCI 20A (4 1/8 x 4 1/8 Cutout)

Product Description

Lew Electric PUFP-CT-WT-PB is a recessed countertop pop-up assembly that integrates a duplex 20A GFCI tamper-resistant receptacle. The unit opens with an oval push button to expose the outlet, includes a plastic back box with threaded lock nut and hardwire knockouts (no cord), and conforms to UL 498, ANSI/UL 943 and NEC 406.5E countertop requirements. Installation requires a 4 1/8 in x 4 1/8 in cutout, 1.97 in clearance beneath the countertop, and supports up to 1.9 in countertop thickness.

• Integrated duplex 20A GFCI with tamper-resistant (TR) plugs, backward compatible with 15A plugs; gasketed bezel for wet-location countertop use
• Recessed pop-up design with oval push button; plastic back box with lock nut and hardwire knockouts for hardwired installation (no cord)
• Meets UL 498 and ANSI/UL 943, certified to CSA STD.C22.2 No. 42-10; ETL/cETL listings; passed half-gallon spill and durability tests

Product Highlights

Recessed countertop pop-up with duplex 20A GFCI TR receptacle, hardwire back box, UL/CSA/ETL certified, NEC 406.5E compliant.

Product Information

Standard Information

• Brand: LEW ELECTRIC
• Manufacturer Part Number: PUFP-CT-WT-PB
• Country of Origin: USA

Technical Specifications

• Brand: Lew Electric
• Manufacturer Part Number: PUFP-CT-WT-PB
• Product Family: PowerUp Square Pop-Ups - PUFP-CT Series
• Type: Kitchen countertop pop-up outlet assembly
• Cover Shape: Square
• Mounting Type: Recessed pop-up (press-to-open)
• Receptacle Type: Duplex GFCI
• Power Rating: 20 A
• Tamper Resistant: Yes
• Weather Resistant: Yes (suitable for wet-location countertop use)
• Back Box: Plastic back box with threaded lock nut; hardwire through knockouts (no power cord)
• Power Connection: Hardwired (no cord)
• Installation Cutout: 4 1/8 in x 4 1/8 in
• Required Depth Beneath Countertop: 1.97 in
• Maximum Countertop Thickness: 1.9 in
• Bezel Size: 4 7/8 in x 4 11/16 in
• Back Box Dimensions: 4.1062 in x 4 in
• Gasket: Gasket under bezel to reduce liquid ingress
• Standards Certifications: Meets UL 498; ANSI/UL 943; Certified to CSA STD.C22.2 No. 42-10
• Listings: ETL listed (US) #4004534; cETL listed (Canada) #4004534; UL listed receptacle E473428
• Tests Passed: Half-gallon spill test; endurance, mechanical, dielectric, temperature tests
• Intended Use: Indoor countertop and other potentially wet recessed locations (kitchens, bars, pantries, garage benches, hotels, airports, restaurants)
• Service Capacity: Single
• Plug Compatibility: Backwards compatible with 15A plugs
• Includes: Plastic back box with threaded lock nut, screws
• Assembled In: Assembled in USA
• Compliance: RoHS and Proposition 65 compliant
