Lew Electric PUFP-CT-B-PB Square kitchen countertop pop-up GFCI 20A (4-1/8 inches x 4-1/8 inches cutout) PUFP-CT-B-AC-PB

Product Description

Lew Electric PUFP-CT-B-PB is a recessed, press-to-deploy countertop pop-up assembly that provides a duplex 20A GFCI tamper-resistant receptacle for kitchen and other wet-location counters. The unit installs in a 4-1/8" x 4-1/8" cutout, fits countertops up to 1.9 inches thick and requires 1.97 inches clearance beneath a 1.0" countertop. It is IP44 splash-rated, UL listed to UL 498 and UL 943, and includes a plastic back box with lock nut for hardwired installation.

• Duplex 20A GFCI tamper-resistant receptacle, backward compatible with 15A plugs
• Flush-recessed press-to-deploy pop-up with gasket under bezel for splash resistance (IP44)
• Installs in 4-1/8" x 4-1/8" cutout, fits up to 1.9" countertop thickness, hardwired through knockouts

Product Highlights

Recessed 20A duplex GFCI pop-up for countertop use; IP44 splash-rated; installs in 4-1/8" cutout

Product Information

Standard Information

• Brand: LEW ELECTRIC
• Manufacturer Part Number: PUFP-CT-B-PB

Technical Specifications

• Brand: Lew Electric
• Manufacturer Part Number: PUFP-CT-B-PB
• Product Type: Kitchen countertop pop-up outlet
• Product Family: PowerUp Square Pop-Ups - PUFP-CT Series
• Application: Kitchen and wet-location countertops
• Cover Shape: Square
• Finish Color: Brass
• Box Material: Plastic
• Service Capacity: Single
• Plug Connection Type: Above surface
• Receptacle Included: Duplex 20A GFCI (tamper-resistant, backward compatible with 15A)
• Rated Current: 20 Amp
• Countertop Cutout: 4-1/8" x 4-1/8"
• Bezel Dimensions: 4 11/16" x 4 11/16"
• Maximum Countertop Thickness: 1.9 inches
• Required Clearance Beneath Countertop: 1.97 inches
• Mounting: Plastic back box with lock nut; recessed flush pop-up; press-to-deploy operation
• Power Connection: Hardwired through knockouts (no power cord)
• IP / Splash Rating: IP44
• Standards / Certifications: Conforms to UL 498 and UL 943; ETL listed (USA) and cETL listed (Canada) #4004534; CSA approved #C22.2; UL listed receptacle E473428
• NEC Compliance: Meets 2023 NEC 406.5E
• Includes: Plastic back box, lock nut, screws
• Suitable Locations: Wet locations such as kitchen countertops, bars, pantries, closets, garage workbenches; commercial: airports, hotels, restaurants
• Operation: Press to pop up and press to close
