Leviton W5661-T0Y Single Receptacle Outlet 15 Amp 250 Volt

Product Description

The LEVITON W5661-T0Y is a heavy-duty industrial specification grade, weather- and tamper-resistant single receptacle outlet. Rated at 15 Amp and 250 Volt, it features back and side wiring and NEMA 6-15R. It offers added protection against corrosion, UV degradation and cold impact damage.

• Heavy-Duty Industrial Specification Grade
• Weather-Resistant
• Accommodates back and side wiring

Product Highlights

This receptacle is ideal for industrial applications and provides reliable performance in harsh environments.

Product Information

Standard Information

• Brand: LEVITON
• Manufacturer Part Number: W5661-T0Y
• Country of Origin: Mexico

Technical Specifications

• Catalog Number: W5661-T0Y
• Manufacturer: Leviton
• Brand: Leviton
• Country of Origin: Mexico
• Made in USA: No
• Amperage Rating: 15
• Application: Industrial
• Number of Poles: 2
• Number of Wires: 3
• Special Features: Heavy-Duty Industrial Specification Grade, Weather-Resistant
• Standard: UL 948, CSA C22.2 no. 42
• UPC: 078477650059
• GTIN: 00078477650059
• Item Type: Single Receptacle Outlet
• Nema: 6-15R
• Amperage: 15 A
• Dielectric Voltage: 2000 VAC
• Grounding: Self-Grounding
• HP Rating: 1-1/2 HP
• Pole: 2
• Temperature Rise: Max 30 C
• Voltage: 250 VAC
• Wire: 3
• Flammability: Rated V-2 per UL 94
• Operating Temperature: Maximum Continuous 75 C, minimum -40 C (w/o impact)
• Body Material: Nylon
• Face Material: PBT
• Ground Contacts: Phosphor Bronze
• Grounding Screw: #8 Brass
• Line Contacts: Brass Triple Wipe 0.040"
• Mounting Screws: #6 Stainless Steel
• Mounting Strap: Nickel-Plated Steel
• Tamper Resistant Shutter Mechanism: Thermoplastic
• Terminal Clamps: Brass
• Terminal Screws: #10 Brass
• Product ID: Ratings are Marked on Device
• Screw Terminal Torque: 14-18 in-lbs
• Terminal Accom.: #14-#10 AWG Solid or Stranded
• Termination: Back and Side Wire
• Feature: Weather- and Tamper-Resistant , Smooth Face , RoHS Compliant
• Grade: Heavy-Duty Industrial Specification Grade
• NEMA Rating: WD-1 and WD-6
• Standards and Certifications: UL 498; CSA C22.2, No. 42; Fed Spec WC-596; NOM
• Mfr. Part Number: W5661-T0Y
• UPC Code: #078477650059
