Leviton W5461-T Single Receptacle Outlet 20 amp 250 volt

Product Description

The LEVITON W5461-T is a heavy-duty industrial specification grade single receptacle outlet. Rated for 20 Amp and 250 Volt, it features a smooth face and is weather-resistant. Designed for back or side wiring with NEMA 6-20R, this 2-pole, 3-wire receptacle is self-grounding.

• Heavy-Duty Industrial Specification Grade
• Weather-Resistant
• Constructed with impact-resistant thermoplastic nylon

Product Highlights

This receptacle provides a reliable and durable solution for industrial applications, offering resistance to weather and corrosion.

Product Information

Standard Information

• Brand: LEVITON
• Manufacturer Part Number: W5461-T
• Country of Origin: Mexico

Technical Specifications

• Catalog Number: W5461-T
• Manufacturer: LEVITON
• Brand: Leviton
• Country of Origin: Mexico
• Made in USA: No
• Amperage Rating: 20 A
• Application: Industrial
• Number of Poles: 2
• Special Features: Heavy-Duty Industrial Specification Grade, Weather-Resistant
• Standard: UL 948, CSA C22.2 no. 42
• UPC: 078477066218
• GTIN: 00078477066218
• Item Type: Single Receptacle Outlet
• Horsepower: 2 hp
• Material: Nylon
• NEMA Rating: NEMA 6-20R
• Number of Wires: 3
• Series: W5461
• Temperature Rating: -40 to 75 deg C
• Terminal Type: Back/Side Wire
• Type: Heavy Duty Single Self-Grounding Smooth Face Weather-Resistant
• Voltage Rating: 250 VAC
• Current Interrupting: Certified for full-rated current and voltage
• Dielectric Voltage: 2000 VAC
• Grounding: Self-Grounding
• Horsepower Rating: 2 HP
• Temperature Rise: Max 30 C
• Voltage: 250 VAC
• Wire: 3
• Flammability: Rated V-2 per UL 94
• Operating Temperature: -40 C to 75 C
• Body Material: Nylon
• Face Material: Nylon
• Ground Clips: Brass
• Ground Contacts: Brass
• Grounding Screw: #8 Brass
• Line Contacts: Brass Triple Wipe 0.031"
• Mounting Screws: #6 Stainless Steel
• Mounting Strap: Nickel-Plated Steel
• Terminal Clamps: Brass
• Terminal Screws: #10 Brass
• Product ID: Ratings are permanently marked on device
• Screw Terminal Torque: 14-18 in-lbs
• Termination: Back and Side Wire
• Wire Gauge: #14-#10 AWG Solid or Stranded
• Device Type: Single Receptacle Outlet
• Feature: Weather Resistant, Smooth Face, RoHS Compliant
• Grade: Heavy-Duty Industrial Specification Grade
• NEMA: WD-1 and WD-6
• Standards and Certifications: UL 948, CSA C22.2 no. 42, Fed Spec WC-596, NOM
